Neutrik Xlr 3 Pin Female Chassis Dlx Velour Chrome Nc3fd-lx-he Nc3fd-lx-he

Be the first to review this product

Availability: In stock

Only 94 left

Excl. Vat: £5.58 Incl. Vat: £6.70
OR

Neutrik XLR 3 PIn Female Chassis DLX Velour Chrome NC3FD-LX-HE NC3FD-LX-HE CONC3FDLXHE By Neutrik

Neutrik Xlr 3 Pin Female Chassis Dlx Velour Chrome Nc3fd-lx-he Nc3fd-lx-he

Double click on above image to view full picture

Zoom Out
Zoom In

More Views

Related links:
Neutrik XLR Chassis

Details

Neutrik XLR 3 PIn Female Chassis DLX Velour Chrome NC3FD-LX-HE NC3FD-LX-HE CONC3FDLXHE

NC3FD-LX-HE
3 pole Female receptacle, solder cups, velour chromium housing, gold contacts
Number of contacts: 3
Contact resistance: 5mOhm
Dielectric strength: 1500Vdc
Rated current per contact: 16A
Rated voltage: 50V
Wiring: Solder contacts
Locking device: latch lock
Mounting direction: front & rear
Chassis shape: D
Shell plating: Velour Chromium


The DLX series features a compact all metal housing with an ingenious duplex ground contact, which offers excellent RF protection and shielding. It is the ideal match for mating with Neutrik EMC XLR cable connector.

Additional Information

SKU FAV-CONC3FDLXHE
Barcode N/A
Manufacturer Neutrik
Manfacturer Code NC3FDLXHE
Series No
