Neutrik Jack Socket 1/4in Vertical PCB Unswitched NJ3FD-V CONJ3FDV

Jack Socket 1/4in Vertical PCB Unswitched

Technical Specifications:

- Non-switching stereo jack (T/R/S)
- Vertical PCB mount panel jack in A-gauge/B-gauge version with gold plated contacts and unique quick fixing cap for rapid panel mounting. Separation of mechanical latch and electrical contacts offers high retention force combined with low insertion force..
- Gender: female
- Dielectric strength: 1 kVdc
- Rated current per contact: 3 A
- Wiring: vertical PCB mount
- Panel thickness: 1.2 - 1.5 mm
- Locking device: retention spring
- Mounting direction: rear
- Chassis shape12 mm
- Shell: polyamide

Priced per connector: available in any quantity
Packing information: box quantity = 100
